1961212
196 Self Closing Thermostatic Shower Mixer
Shower thermostat self-closing mixer for concealed installation
Thermostatic Concealed Selfclosing Shower Mixer 1/2" (DN15), with Time Adjustment from 10 - 40 sec., incl. Backflow Preventer, Protecting Strainers, Connection 1/2" (DN15)
GTIN
4260146231966
Properties
Settings
Technical details
Packing information
Actuation
Push button activation
Connection
G 1/2, concealed
Flow rate (3 bar)
20 l/min
Running time
ca. 25 seconds, pre-set
Temperature control
Temperature handle with safety stop at 38°C
Operation
Thermostat + self-closing cartridge
Installation
wall mounted
Color
Chrome
Running time
adjustable from 10 - 40 seconds
with regulating screw
Connection size
G 1/2
DN Size
DN 15
Working pressure
0,5 - 5 bar, max.pressure difference of 2 bar
Hot water temperature
65 ° C, short-term higher thermal disinfection
Backflow prevention
Yes
Stop valve
Yes
Certificates
Hyigenezertifikat Polen;
Measure A (mm)
260
Measure B (mm)
260
Measure C (mm)
160
Weight (kg)
2,850
5951209
Vandal-proof shower head, 9 l/min.
5951207
Vandal-proof shower head, 6 l/min.
5951204
Head shower 25 l/min., 190mm
5951202
Head shower 20 l/min., 180mm
Spareparts
