1922035

192 Self Closing Shower Valve

Self-closing shower valve 1/2", concealed

Concealed Self Closing Shower Valve 1/2", Running Time about 15 sec(at 2 bar) pre-set


GTIN

4260146231928

Properties
Settings
Technical details
Packing information
Actuation
Push button activation
Connection
G 1/2, concealed
Running time
ca. 15 seconds
Temperature control
cold or premixed water
Operation
Self-closing cartridge
Installation
wall mounted
Color
Chrome
Connection size
G 1/2
DN Size
DN 15
Working pressure
0,5 - 5 bar
Hot water temperature
max. 70° C
Certificates
Hyigenezertifikat Polen;
Measure A (mm)
278
Measure B (mm)
131
Measure C (mm)
66
Weight (kg)
1,350
Related to

5951209

Vandal-proof shower head, 9 l/min.

5951207

Vandal-proof shower head, 6 l/min.

5951204

Head shower 25 l/min., 190mm

5951202

Head shower 20 l/min., 180mm

Spareparts

8006973

Push button spring 890/880/670/610/688

1003063

Push-button spring 174/175/185/196/877

8009222

allen key 2,5 mm
